CY8C24x94

CAPSENSE? Plus CY8C24x94 family supports up to 56 general-purpose I/Os for buttons, touchpads, LEDs, and other general-purpose functions.

anchor

Â鶹¹ÙÍø

About

Analog PSOC blocks

Six rail-to-rail analog PSOC blocks provide:

  • Up to 14-bit analog-to-digital converters (ADCs)
  • Up to 9-bit digital-to-analog converters (DACs)
  • Programmable gain amplifiers (PGAs)
  • Programmable filters and comparators
Digital PSOC blocks

Four digital PSOC blocks provide:

  • 8- to 32-bit timers, counters, and pulse width modulators (PWMs)
  • Cyclical redundancy check (CRC) and pseudo random sequence (PRS) modules
  • Full-duplex universal asynchronous receiver transmitter (UART)
  • Multiple serial peripheral interface (SPI) masters or slave
  • Connectable to all general-purpose I/O (GPIO) pins
Additional Features

Programmable pin configurations

  • 25-mA sink, 10-mA source on all GPIOs
  • Pull-up, pull-down, high Z, strong, or open-drain drive modes on all GPIOs
  • Up to 48 analog inputs on GPIOs
  • Two 33 mA analog outputs on GPIOs
  • Configurable interrupt on all GPIOs

Additional system resources

  • I2C slave, master, and multi-master to 400 kHz
  • Watchdog and sleep timers
  • User-configurable low-voltage detection (LVD)

?

Getting Started
  • DOWNLOAD the Getting started with CAPSENSE? Design Guide
  • INSTALL PSOC? Designer to begin development
  • READ AN49079 to learn how to dynamically configure your CAPSENSE? Plus controller

Analog PSOC blocks

Six rail-to-rail analog PSOC blocks provide:

  • Up to 14-bit analog-to-digital converters (ADCs)
  • Up to 9-bit digital-to-analog converters (DACs)
  • Programmable gain amplifiers (PGAs)
  • Programmable filters and comparators

Digital PSOC blocks

Four digital PSOC blocks provide:

  • 8- to 32-bit timers, counters, and pulse width modulators (PWMs)
  • Cyclical redundancy check (CRC) and pseudo random sequence (PRS) modules
  • Full-duplex universal asynchronous receiver transmitter (UART)
  • Multiple serial peripheral interface (SPI) masters or slave
  • Connectable to all general-purpose I/O (GPIO) pins

Additional Features

Programmable pin configurations

  • 25-mA sink, 10-mA source on all GPIOs
  • Pull-up, pull-down, high Z, strong, or open-drain drive modes on all GPIOs
  • Up to 48 analog inputs on GPIOs
  • Two 33 mA analog outputs on GPIOs
  • Configurable interrupt on all GPIOs

Additional system resources

  • I2C slave, master, and multi-master to 400 kHz
  • Watchdog and sleep timers
  • User-configurable low-voltage detection (LVD)

?

Getting Started
  • DOWNLOAD the Getting started with CAPSENSE? Design Guide
  • INSTALL PSOC? Designer to begin development
  • READ AN49079 to learn how to dynamically configure your CAPSENSE? Plus controller
