AURIX? TC39xXE (emulation devices)

A specialized AURIX? TC3xx MCU family with debugging, tracing, measuring, and calibrating capabilities

anchor

Overview

AURIX? TC39x Emulation Devices (TC39xXE) family offers the same feature set as the TC39x standard devices with additional debug and tracing capabilities. The AURIX? TC39xXE supports calibration, rapid prototyping, instrumentation, and debug/emulation. It can emulate both TC39x standard devices (6 CPUs) and TC38x standard devices (4 CPUs).

Key Features

  • Six TriCore? with 300 MHz?(DSP)
  • 16 MB flash with ECC
  • Up to 6.9 MB SRAM with ECC
  • 128x?DMA?channels, GTM,?CCU6,?GPT12
  • 1 GbE, 12xCAN, 2xFlexRay, 12xASCLIN
  • 6xQSPI, 2xI?C, I?S, 2xHSSL, 4xMSC
  • 25xSENT, 4xPSI5, 1xPSI5S, eMMC/SDIO
  • LFBGA-292, LFBGA-516
  • ISO 26262/IEC61508 up to ASIL-D
  • AUTOSAR?4.2 support, EVITA full?HSM
  • Single supply 5 V or 3.3 V
  • Temperature: -40¡ãC to +125¡ãC/+150¡ãC

Â鶹¹ÙÍø

About

Emulation features
  • 4 MB Extension Memory (EMEM) for calibration and tracing (2 MB)
  • Multi-Core Debug Solution (MCDS): Parallel and time-aligned trace of cores and busses, powerful trigger conditions, on-chip logic analyzer functions
  • Additional DAP interface (DAPE) for connecting a second, independent tool
  • Injector for faults and stress (IFS)
  • Aurora Gigabit Trace (AGBT) support
  • CPUs have full access to all emulation resources, enabling all types of interfaces (e.g., Ethernet) as tool connection

MCDS tracing can be evaluated using the free-of-charge MCDS Trace Viewer tool which comes with the DAS installation (/DAS).

Benefits
  • Higher software/system quality and faster time-to-market with best-in-class: multi-core debugging and trace, trace-based measurement, rapid prototyping, calibration
  • Scalable tooling options from very cost-effective to highest performance
  • Strong AURIX? TC3xx compatibility: maintains investment in tools and knowledge, early availability of attractive tooling solutions, minimizes risk
  • Different tool combinations due to two DAP interfaces
  • Very cost-effective trace
  • Consistent architecture over the whole family for all packages
Compatibility with AURIX? TC39x and AURIX? TC38x

AURIX? TC39xXE emulation family is fully compatible with AURIX? TC39x standard devices.?

For AURIX? TC38x systems, consider the following:

Thermal design and power supply must support TC39xXE¡¯s higher power consumption

Software needs to be tolerant to the different CHIPID and JTAGID values

The upper 12 ASCLIN modules (out of 24) of TC38x may not be used

Software Support

AURIX? development studio
It is a comprehensive development environment, including Eclipse IDE, C-Compiler, Multi-core Debugger, Infineon low-level driver (iLLD), with no time and code-size limitations that enables editing, compiling, and debugging of application code.

AUTOSAR MCAL drivers
Infineon's MC-ISAR?AUTOSAR drivers are based on AUTOSAR-verified technology and comprise components of the Microcontroller Abstraction Layer (MCAL) in one configuration tool for rapid application development.

AURIX? iLLD Drivers
AURIX? -?Infineon Low Level Driver

AURIX? TC3xx Safety Software SBST Deliverables
SBST for non LS CPU¨C supporting ASIL-B
The CPU Software Based Self Test (SBST) is a safety mechanism that supports the ISO26262 SPFM for ASIL B safety goals.
Required for applicants with an ASIL B requirement on AURIX? TC3xx non-lockstep CPUs.

SBST for SPU ¨C supporting ADAS cluster ASIL-C applications
The SPU Software Based Self Test (SBST) is similar in concept to the CPU SBST described above.

Drive Core for AURIX?
Infineon¡¯s AURIX? Drive Core is a scalable software bundle that accelerates development, simplifies migration, and reduces commercial and supplier management complexities.

Drive Core for AURIX?
AURIX? Preferred Design Houses (PDH)

Our AURIX? preferred design houses is a trusted partners' ecosystem that extends the support force by tailoring their know-how to meet your specific needs.

By partnering with one of our qualified preferred design houses, you can be assured that you'll receive expert advice and customized support to help you achieve your goals. Our team of professionals brings added value to customer service, working together to optimize your design and help you succeed in your business objectives.

We understand that every customer is unique, which is why we offer tailored solutions to meet your specific needs. From product-specific support to application-specific advice, our preferred design house is fully trained to use AURIX? and provides a wealth of knowledge and expertise to help you succeed.

Together with our partners, we offer optimized customer support for systems using our products. Our preferred design houses are committed to delivering exceptional service and support to ensure your success. So why wait? Contact us today to learn more about how our AURIX? preferred design house can help you achieve your goals and take your business to the next level.

Learn more about AURIX? Preferred Design Houses
AURIX? digital and technical documentation

Access to AURIX? Digital collaterals

Discover the future of marketing with our cutting-edge digital collaterals, seamlessly integrated into HTML for a streamlined, interactive experience. Our all-in-one solution ensures that all your marketing assets, from datasheets and user manuals to code examples and presentations, are easily accessible and beautifully displayed across any device.

Access to additional AURIX? technical documentation

Register to the myInfineon Collaboration Platform (myICP) and gain access to additional microcontroller information: Technical add-on documentation, training, tools, and much more. Follow these steps to get started:

1. Sign up to myInfineon here.

2. Send your access request to AURIX@infineon.com (with your company email address).

3. You will receive a confirmation explaining how to use your new access.

myICP
How to register

Microcontroller Training and Video Hub

Dive into the Microcontroller Training and Video Hub and explore expert tutorials, hands-on guides, and in-depth trainings on AURIX? development Studio. Whether you're a beginner or a professional, learn the full potential of AURIX?.

Microcontroller Training and Video Hub
