PSOC? Control C3 Main Line

Unlock real-time control and increased system efficiency with PSOC? Control C3 Main Line

古勣

PSOC? Control C3 Main Line is based on the Arm? Cortex?-M33, running at 180 MHz, with DSP and FPU capability. In addition to the CPU, the devices contain advanced real-time control peripherals, such as high-performance ADC, comparators, ?high-resolution timers and many communication interfaces. Typical applications include HVACs, home appliances, solar, PSUs and EV chargers.

麼な字嬬

  • 180 MHz Arm? Cortex?-M33
  • Up to 256KB read-while-write flash
  • 64KB SRAM with ECC
  • CORDIC math coprocessor
  • 12-Msps, 12-bit "Idle sampling" ADC
  • High resolution PWMs (HRPWM)
  • PSA L2 device security
  • Secure boot
  • 6 power modes with deep sleep

Compare families

Please choose a valid product table template page

Product Table

About

Motor Control (C3M5) and Power Conversion (C3P5)

The Main line of PSOC? Control C3 offers high performance for motor drive and digital power applications.?

PSOC? Control C3M5 for motor control

C3M5 is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), or requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density.?

PSOC? Control C3P5 for power conversion

C3P5 integrates advanced real-time analog peripherals and a leading-edge digital feature set? to improve efficiency and reliability of new designs.?

ModusToolbox?

The leading-edge design environment, ModusToolbox? allow developers to bring their solutions to market quickly and make the best use of the unique feature set that this product offers.?

High Performance Real Time Control

PSOC? Control C3 Main Line will offer the best performance possible with high real time control capability.? This is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), high efficiency and high power density Switched-mode power supplies (SMPS) or digital power, or any application requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • < 80 ps High Resolution PWM (HRPWM) for period, duty & dead time
  • Real-time control, 16 channels-16 bit and 4 channels-32 bit TCPWMs motor control timers
  • CORDIC math coprocessor
  • Packages:? 48, 64, or 80 pins

Security and Safety

Both Safety and Security are fundamental prerequisites for secure, reliable and sustainable industrial applications. It is a must consider for operations, sensitive informations, and authorized control.

PSOC? Control C3 Main Line offers:

  • Security: PSA L2 certified, Configurable Flash Partitioning / Protection?
  • Safety: Class B and SIL 2 compliant safety test libraries

Ease of use for developers

PSOC? Control C3 is supported by ModusToolbox?, a unified ecosystem platform with tools and software solutions. ModusToolbox? Motor Suite, and Power Suite are available for developers of PSOC? Control C3 focus applications. These suites provide a seamless graphical user interface that streamlines evaluation and training, and provide real-time parameter monitoring for valuable insights into performance, efficiency, and reliability. Specialized application environments enable engineers to quickly identify issues, optimize designs, and enhance overall functionality.

ModusToolbox? software
ModusToolbox? for motor control
ModusToolbox? for power conversion

Getting Started

  • GET?the PSOC? Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
  • DOWNLOAD ModusToolbox? software?
  • READ AN238329 - Getting started with PSOC? Control C3 MCU on ModusToolbox? software?
PSOC? Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
ModusToolbox? software
AN238329 application note

Motor Control (C3M5) and Power Conversion (C3P5)

The Main line of PSOC? Control C3 offers high performance for motor drive and digital power applications.?

PSOC? Control C3M5 for motor control

C3M5 is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), or requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density.?

PSOC? Control C3P5 for power conversion

C3P5 integrates advanced real-time analog peripherals and a leading-edge digital feature set? to improve efficiency and reliability of new designs.?

ModusToolbox?

The leading-edge design environment, ModusToolbox? allow developers to bring their solutions to market quickly and make the best use of the unique feature set that this product offers.?

High Performance Real Time Control

PSOC? Control C3 Main Line will offer the best performance possible with high real time control capability.? This is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), high efficiency and high power density Switched-mode power supplies (SMPS) or digital power, or any application requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • < 80 ps High Resolution PWM (HRPWM) for period, duty & dead time
  • Real-time control, 16 channels-16 bit and 4 channels-32 bit TCPWMs motor control timers
  • CORDIC math coprocessor
  • Packages:? 48, 64, or 80 pins

Security and Safety

Both Safety and Security are fundamental prerequisites for secure, reliable and sustainable industrial applications. It is a must consider for operations, sensitive informations, and authorized control.

PSOC? Control C3 Main Line offers:

  • Security: PSA L2 certified, Configurable Flash Partitioning / Protection?
  • Safety: Class B and SIL 2 compliant safety test libraries

Ease of use for developers

PSOC? Control C3 is supported by ModusToolbox?, a unified ecosystem platform with tools and software solutions. ModusToolbox? Motor Suite, and Power Suite are available for developers of PSOC? Control C3 focus applications. These suites provide a seamless graphical user interface that streamlines evaluation and training, and provide real-time parameter monitoring for valuable insights into performance, efficiency, and reliability. Specialized application environments enable engineers to quickly identify issues, optimize designs, and enhance overall functionality.

ModusToolbox? software
ModusToolbox? for motor control
ModusToolbox? for power conversion

Getting Started

  • GET?the PSOC? Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
  • DOWNLOAD ModusToolbox? software?
  • READ AN238329 - Getting started with PSOC? Control C3 MCU on ModusToolbox? software?
PSOC? Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
ModusToolbox? software
AN238329 application note
